Fire protective signaling circuits. Also for smoke detectors, voice communications, audio control and initiating circuits. Article 760 of the NEC. For use in plenum spaces. Minimum Temperature 0ºC , Maximum Temperature 75ºC
| Cable Type | Cond. Size | Conductor Number | Cond. Type | Cond. Strands | Diameter Over Conductor (in) (cm) | Insulation Thickness (mils) (mm) | Jacket Thickness (mils) (mm) | Approx. OD (in) (cm) | Copper Weight (lbs/1000') (kgs/km) | Approx. Weight (lbs/1000') (kgs/km) | DC Resistance at 25C (ohms/1000') (ohms/km) | AC Resistance at 75C (ohms/1000') (ohms/km) | Inductive Reactance (ohms/1000') (ohms/km) | Min. Bend Radius (in) (cm) | Allowable Ampacity Raceway 75C | Allowable Ampacity Raceway 90C | |
| More Options |
FPLP
FPLP
|
18 AWG
18 AWG
|
2
2
|
Cu
Cu
|
7
7
|
0.045
0.11
|
10
0.25
|
15
0.38
|
0.152
0.39
|
10
15
|
16
24
|
6.669
9.92
|
8.035
11.96
|
0.036
0.05
|
0.6
1.52
|
-
-
|
14
14
|
| More Options |
FPLP
FPLP
|
16 AWG
16 AWG
|
2
2
|
Cu
Cu
|
7
7
|
0.056
0.14
|
10
0.25
|
15
0.38
|
0.180
0.46
|
16
24
|
24
36
|
4.181
6.22
|
5.037
7.50
|
0.033
0.05
|
0.7
1.78
|
-
-
|
18
18
|
| More Options |
FPLP
FPLP
|
14 AWG
14 AWG
|
2
2
|
Cu
Cu
|
7
7
|
0.070
0.18
|
10
0.25
|
15
0.38
|
0.206
0.52
|
25
37
|
34
51
|
2.631
3.92
|
3.170
4.72
|
0.058
0.09
|
0.8
2.03
|
20
20
|
25
25
|
