Southwire’s Airport Lighting Cable meets the requirements of (FAA) L-824 C underground electrical cable for airport lighting circuits (AC 150/5345-53D), (AC 150/5345-7F). Southwire’s Airport Lighting Cable is available in sizes #8 AWG through #4 AWG 7 strands. The conductors are bare annealed copper class B and covered with an abrasion, moisture, and heat resistant Cross-Linked Polyethylene XLPE insulation. The 5KV non-shielded cable is available in Black, Red and Yellow colors. South- wire Airport Lighting Cable is primarily used for series lighting circuits for runways, control systems, and other multi-purpose installations. It can be used in direct burial, conduit, or raceways. These cables are capable of operating continuously at a conductor temperature not in excess of 90°C for normal operation, 130°C for emergency and 250°C for short circuit conditions. Silicone Free.
|Stock #||55152799 55152799|
|No. of Conductors||0 0|
|Size (AWG or kcmil) (mm2)||4 AWG 4 AWG|
|No. of Strands||7 7|
|Insulation Thickness (mils) (mm)||110 2.79||mils mm|
|Nom. OD (mils) (mm)||460 11.68||mils mm|
|Nominal Total Weight (lbs/1000') (kgs/km)||181 269||lbs/1000' kgs/km|
