15kV AAC CAMV™ Spacer Cable
Aluminum Conductors. Track-Resistant HD Polyethylene.
Application
Used for primary and secondary overhead distribution where limited space is available or desirable for rights of way. Installed as an uninsulated conductor; however, covering is effective in preventing direct shorts and instantaneous flashovers should tree limbs or other objects contact conductors in such close proximity. The resulting close-proximity configuration minimizes the amount of space and hardware required for line installation; particularly useful in congested areas such as alleyways or tight corridors.
Specifications
| Conductor | Ground Wire | ||||||||
| No. of Conductors | Size (AWG or kcmil) (mm2) | No. of Strands | Insulation Thickness (mils) (mm) | Size (AWG) | No. of Strands | Nom. OD (mils) (mm) | Nominal Total Weight (lbs/1000') (kgs/km) | Allowable Ampacity | |
| 613415 |
1
1
|
2/0 AWG
2/0 AWG
|
7
7
|
|
|
|
676
17.17
|
227
338
|
|
| 603915 |
1
1
|
4/0 AWG
4/0 AWG
|
7
7
|
|
|
|
805
20.45
|
338
503
|
|
| 256123 |
1
1
|
336.4 KCMIL
336.4 KCMIL
|
19
19
|
|
|
|
933
23.70
|
485
721
|
|
| 606901 |
1
1
|
397.5 KCMIL
397.5 KCMIL
|
19
19
|
|
|
|
959
24.36
|
531
790
|
|
| 151357 |
1
1
|
477 KCMIL
477 KCMIL
|
19
19
|
|
|
|
1022
25.96
|
618
920
|
|
| 613897 |
1
1
|
556.5 KCMIL
556.5 KCMIL
|
37
37
|
|
|
|
1120
28.45
|
739
1100
|
|
| 622913 |
1
1
|
636 KCMIL
636 KCMIL
|
37
37
|
|
|
|
1175
29.85
|
827
1230
|
|
| 614530 |
1
1
|
795 KCMIL
795 KCMIL
|
37
37
|
|
|
|
1252
31.80
|
973
1448
|
|
Standards & References
Southwire’s 15kV – 35kV covered multi-layer tree wire meets or exceeds all applicable ICEA specifications and the following ASTM specifications:
- ASTM B230
- ASTM B231
Construction
Conductors are concentrically stranded, AAC (1350-H19), either compressed or full compact depending on conductor size, AAAC. High-density track-resistant polyethylene.
- 1350
