1/0-19 CU 4/C 55 MILS XHHW-2 1X6 CU GW AIA PVC 600V

SKU: 89022999
Type MC Power Cable 600Volt Three Conductor Copper, Cross Linked Polyethylene (XLPE) insulation XHHW-2 Aluminum Interlocked Armor (AIA), Polyvinyl Chloride (PVC) Jacket with 1 Bare CU Ground. Silicone Free.
Download Category Specifications:
Excel Table
Select Product Specifications
Construction
Outer Jacket / Armor Color
Conductor Color
Packaging

Application

Specifications

measurement
imperial metric
Stock # 89022999 89022999
No. of Conductors 4 4
Size (AWG or kcmil) 1/0 AWG 1/0 AWG
No. of Strands 19 19
Insulation Thickness (mils) (mm) 55 1.40 mils mm
Nom. OD (mils) (mm) 1452 36.90 mils mm
Nominal Total Weight (lbs/1000') (kgs/km) 1902 2831 lbs/1000' kgs/km

Standards & References

Construction

Resources

There are no downloadable resources for this product.
