T90 SIMpull™ CU
SIMpull® THHN THWN-2 MTW / c(UL) T90 Nylon TWN75 Copper Conductor, 600V, Thermoplastic-Insulated Cable, All Sizes Rated TWN75
Application
SIMpull ® THHN" THWN-2" MTW - (UL) - suitable for dry locations not exceeding 90°C. For Gasoline and Oil Resistant II applications not to exceed 75°C. MTW (UL) - suitable for dry locations not exceeding 90°C. For wet locations" Gasoline and Oil Resistant II applications not to exceed 60°C. T90 Nylon c(UL) - cables are primarily intended for installation in conduit (raceways) as exposed wiring in dry locations not exceeding 90°C. TWN75 c(UL) - suitable for wet or dry locations at not more than 75°C. The maximum voltage rating for all intended applications is 600 volts. Minimum installation handling temperature is limited to -25°C. Minimum operating temperature limited to -40°C.
Specifications
| Conductor | Allowable Ampacities+ | ||||||||
| Size (AWG or kcmil) (mm2) | No. of Strands | Insulation Thickness (mils) (mm) | Jacket Thickness (mils) (mm) | Nom. OD (mils) (mm) | Nominal Total Weight (lbs/1000') (kgs/km) | Allowable Ampacity at 60C | Allowable Ampacity at 75C | Allowable Ampacity at 90C | |
| 507665 |
14 AWG
14 AWG
|
1
1
|
15
0.38
|
5
0.13
|
106
2.69
|
16
23
|
15
15
|
20
20
|
25
25
|
| 472001 |
14 AWG
14 AWG
|
19
19
|
15
0.38
|
5
0.13
|
113
2.87
|
16
24
|
15
15
|
20
20
|
25
25
|
| 495770 |
12 AWG
12 AWG
|
1
1
|
15
0.38
|
5
0.13
|
122
3.12
|
24
35
|
20
20
|
25
25
|
30
30
|
| 472050 |
12 AWG
12 AWG
|
19
19
|
15
0.38
|
5
0.13
|
132
3.35
|
25
36
|
20
20
|
25
25
|
30
30
|
| 484626 |
10 AWG
10 AWG
|
1
1
|
20
0.51
|
5
0.13
|
153
3.91
|
37
56
|
30
30
|
35
35
|
40
40
|
| 472100 |
10 AWG
10 AWG
|
19
19
|
20
0.51
|
5
0.13
|
165
4.19
|
39
58
|
30
30
|
35
35
|
40
40
|
| 472159 |
8 AWG
8 AWG
|
19
19
|
30
0.76
|
6
0.15
|
217
5.51
|
63
94
|
40
40
|
50
50
|
55
55
|
| 472209 |
6 AWG
6 AWG
|
19
19
|
30
0.76
|
6
0.15
|
253
6.43
|
96
143
|
55
55
|
65
65
|
75
75
|
| 472258 |
4 AWG
4 AWG
|
19
19
|
40
1.02
|
7
0.18
|
324
8.23
|
154
229
|
70
70
|
85
85
|
95
95
|
| 484667 |
3 AWG
3 AWG
|
19
19
|
40
1.02
|
7
0.18
|
352
8.94
|
191
284
|
85
85
|
100
100
|
115
115
|
| 672386 |
2 AWG
2 AWG
|
19
19
|
40
1.02
|
7
0.18
|
384
9.75
|
236
352
|
95
95
|
115
115
|
130
130
|
| 684084 |
1 AWG
1 AWG
|
19
19
|
50
1.27
|
8
0.20
|
441
11.20
|
302
449
|
110
110
|
130
130
|
145
145
|
| 684084 |
1 AWG
1 AWG
|
19
19
|
50
1.27
|
8
0.20
|
441
11.20
|
302
449
|
110
110
|
130
130
|
145
145
|
| 471979 |
1/0 AWG
1/0 AWG
|
19
19
|
50
1.27
|
8
0.20
|
480
12.19
|
374
557
|
125
125
|
150
150
|
170
170
|
| 588919 |
2/0 AWG
2/0 AWG
|
19
19
|
80
2.03
|
|
572
14.53
|
489
728
|
145
145
|
175
175
|
195
195
|
| 471987 |
3/0 AWG
3/0 AWG
|
19
19
|
50
1.27
|
8
0.20
|
574
14.58
|
579
862
|
165
165
|
200
200
|
225
225
|
| 677820 |
4/0 AWG
4/0 AWG
|
19
19
|
50
1.27
|
8
0.20
|
630
16.00
|
724
1077
|
195
195
|
230
230
|
260
260
|
+ Allowable ampacities are for general use as specified by the Canadian Electrical Code, Part 1, 2015, Table 2
Standards & References
Southwire’s SIMpull® THHN" THWN-2" MTW cables meet or exceed the following requirements:
- ASTM B3" B8 and B787
- Built to CSA C22.2 No.75" LL90458
- -25°C Cold Bend Test Compliant
- Canadian Electrical Code
- CSA FT-1 - Flame Test
- UL" c(UL) and CSA listed
Construction
Southwire’s SIMpull ® THHN" THWN-2" MTW cables are manufactured with annealed (soft) copper conductor and a tough" heat and moisture-resistant thermoplastic polyvinyl chloride (PVC) insulation.
- Sizes AWG 14 (19) through AWG 4/0 (19) are manufactured using combination unilay stranding; all other stranded sizes are manufactured using compressed stranding.
- Construction is available in black" white" red" blue" green" yellow" brown" orange and gray. Some colours are subject to economic order quantity.
